48V 500A DC SepEx Golf Cart Controller for EZGO Club Car Yamaha Curtis 1268-5501
$ 216.48
Description
Store Categories Store Categories Golf Cart Controller Aerial Lift Controller Agriculture Vehicle Controller Material Handling Controller Other 48V 500A DC SepEx Controller for Curtis EZGO Club Car Yamaha Golf Cart 1268-5501 Product Description The separately excited motor speed controller, Curtis Controller Model 1268-5501, operates at a high frequency of 16 kHz, making them a noiseless and cost-efficient choice as they allow smooth control of brake, torque, and speed. It is designed to suit heavy-duty transport vehicles ranging from high-power demand golf carts to utility vehicles. The Curtis 1268-5501 is a 36-48-volt model with 500 amperes current limit and utilizes a 0-5K ohms throttle input. It weighs 3.9 kg and is 229 mm in length, 178 mm in width, and 81 mm in depth. The design is particularly similar to Curtis 1266 but is more suitable for heavier applications. The design is particularly similar to Curtis 1266 but is more suitable for heavier applications. This controller has regenerative braking and programmable parameters as its key features. It also has well-protected components, cutback functions, mobilization control, and WalkAway feature among others. SPECIFICATIONS NOMINAL VOLTAGE RANGE 36-48 V MINIMUM ELECTRICAL ISOLATION Due to Heatsink: 500 VAC LOGIC INPUT Power Input Voltage 16.8 V Power Input Current W/o Programmer: 160 mA W/ Programmer: 200 mA Voltage High: Greater than 20 V Low: Less than 7.5 V Current 10 mA CURRENT LIMIT 500 A 2 MINUTE RATING Armature: 500 A Field: 50 A OPERATING FREQUENCY 16 kHz THROTTLE INPUT 0-5K ohms TEMPERATURE Ambient (Operational) -40°C to 50°C Under temperature Cutback (Heatsink) -25 °C (50% armature current) Overtemperature Cutback (Heatsink) Starts at 85 °C Cutoff finishes at 95°C PHYSICAL SPECIFICATIONS WEIGHT 3.9 kg DIMENSION Length 229 mm Width 178 mm Depth 81 mm PACKAGING IP64, IP67 FEATURES Feature Purpose Regenerative Braking Ensures longer operation, reduces motor heating, and decreases brush wear Adjustable and Programmable Parameters A feature allowing control of brake, speed, and torque and to match motor requirements MultiMode input The top speed of the vehicle is controlled and with applied limits along with 2 operating personalities Hall Effect Speed Sensor The speed control is improved due to this feature Anti-rollback function When driving uphill, the vehicle is inhibited to roll backward Anti-stall function Protects motor commutator from harm High Pedal Disable Allows a safe start by monitoring the status of the throttle. If the vehicle is started with an applied throttle, this feature disables it from operating until the throttle is returned to the neutral position WalkAway braking The vehicle can only operate at low speeds when off Reverse Signal Driver If the vehicle is reversing, it gives a low signal Short Circuit Protection Outputs and has integrated protection from coil spike Buzzer Sound Reverse: Steady WalkAway Braking: Intermittent Status LED Allows viewing of diagnostics Plastic Cover Helps in resisting splashes Easy Installation No further alterations are necessary IP64 and IP67 Ingress Protection (IP) rating that protects the controller from the rugged environment ACCESSORIES COMPATIBLE WITH CURTIS 1268 Curtis 1314 - a compatible 32-bit application that runs on personal computers with Windows as an operating system that functions similarly to the handheld Curtis controller. Curtis 1311 - a programmer that assists in parameter control and system diagnostics. DIMENSIONS WIRING DIAGRAM Wiring Diagram for 1268 with EM brake Wiring Diagram for 1268 with WalkAway function Copyright © 2023 Dianxiaomi
