DC12V 3A 4 Wire PWM PC CPU Fan Temperature Control Thermostat Speed Controller

Description

Store Categories Store Categories Other Product View Details Feature: 1. Using high-quality materials, the quality is guaranteed 2. The appearance of the product is exquisite and small 3. Supports low temperature shutdown of fans within 3A, can directly turn off the fan power, and supports back-sequence fans 4. The product wiring is simple and convenient 5. Support four-wire fan speed regulation Specification: Design power supply voltage: DC12V Voltage range: DC8-16V (circuit operating voltage, please pay attention to the fan voltage range) Circuit self-consumption: less than 40mA (tested at 12V) Fan current: no more than 3.3A PWM range: 1-100 (signal percentage is not actual speed ±0.5%) PWM frequency: 25KHZ (plus or minus 1KHZ) PWM signal amplitude: 5V (no load) Temperature measurement range: -9.9-99.9℃ Temperature measurement error: the error in the range of 0-50°C is lower than 1.2°C, and the error in other ranges is lower than 2°C Precautions: 1. This control only controls the speed adjustment of the fan controlled by the four-wire standard PWM signal. The signal specification is 25KHZ 5V. Conventional chassis, CPU and many server four-wire fans support it, but it cannot control the speed regulation of 2-3 wire fans! 2. The difference between the acceleration temperature and the full speed temperature should not be lower than 5°C, and the difference between the shutdown temperature and the acceleration temperature should not be lower than 2°C. When modifying the parameters, if the value breaks the above temperature difference, the program will automatically adjust the other two parameters. Show description: Three-digit digital tube: display specific parameters and values LED "×10 RPM": Speed unit light This light is on and the digital tube displays the fan speed. The value is the value after dividing the speed by 10. For example, if 256 is displayed, the actual fan speed is 2560RPM (revolution/min) LED "℃": temperature unit light, this light is on and the digital tube displays the temperature measured by the current probe LED "RUN": Fan running indicator light on when the fan is running and off when the fan is off Package List: 1x Module 1x Sensing wire Shipping Policy Payment Method Returns Policy Shipping Policy Payment Method Returns Policy Home Payment Shipping About us Contact us Copyright©2018 datacaciques Home Payment Shipping About us Contact us Store Categories Store Categories Other Product View Details Feature: 1. Using high-quality materials, the quality is guaranteed 2. The appearance of the product is exquisite and small 3. Supports low temperature shutdown of fans within 3A, can directly turn off the fan power, and supports back-sequence fans 4. The product wiring is simple and convenient 5. Support four-wire fan speed regulation Specification: Design power supply voltage: DC12V Voltage range: DC8-16V (circuit operating voltage, please pay attention to the fan voltage range) Circuit self-consumption: less than 40mA (tested at 12V) Fan current: no more than 3.3A PWM range: 1-100 (signal percentage is not actual speed ±0.5%) PWM frequency: 25KHZ (plus or minus 1KHZ) PWM signal amplitude: 5V (no load) Temperature measurement range: -9.9-99.9℃ Temperature measurement error: the error in the range of 0-50°C is lower than 1.2°C, and the error in other ranges is lower than 2°C Precautions: 1. This control only controls the speed adjustment of the fan controlled by the four-wire standard PWM signal. The signal specification is 25KHZ 5V. Conventional chassis, CPU and many server four-wire fans support it, but it cannot control the speed regulation of 2-3 wire fans! 2. The difference between the acceleration temperature and the full speed temperature should not be lower than 5°C, and the difference between the shutdown temperature and the acceleration temperature should not be lower than 2°C. When modifying the parameters, if the value breaks the above temperature difference, the program will automatically adjust the other two parameters. Show description: Three-digit digital tube: display specific parameters and values LED "×10 RPM": Speed unit light This light is on and the digital tube displays the fan speed. The value is the value after dividing the speed by 10. For example, if 256 is displayed, the actual fan speed is 2560RPM (revolution/min) LED "℃": temperature unit light, this light is on and the digital tube displays the temperature measured by the current probe LED "RUN": Fan running indicator light on when the fan is running and off when the fan is off Package List: 1x Module 1x Sensing wire Shipping Policy Payment Method Returns Policy Shipping Policy We will arrange shipping for you within 24 Hours after payment cleared except the holidays. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. Payment Method We accept PayPal payment ONLY, and must be received within 5 days from the date of purchase. 2. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. 3.Buyers are responsible for import duties,custom fees and taxes, if any, please check your country. Returns Policy 1.We believe our items are so outstanding. We are convinced you will be happy with your Purchase. 2. If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund or resend the item to you after the returned item arrived at our warehouse. 3. Please include your eBay ID and item number with any email requests.
